Over the past decade, rainscreen wall assemblies have significantly reshaped building design and performance. This evolution isn’t surprising: rainscreens offer superior water management, improved thermal efficiency, and diverse design options, pushing the capabilities of the building envelope to new heights.

The rising popularity of rainscreens has led to the establishment of the Rainscreen Association in North America, which has already made a major impact by securing the formal definition of a rainscreen in the 2024 edition of the International Building Code:

Rainscreen System: An assembly applied to the exterior side of an exterior wall and consisting of, at minimum, an outer layer, an inner layer, and a cavity between them sufficient for the passive removal of liquid water and water vapor.

This definition is now incorporated under “exterior wall covering” in Chapter 2 of the IBC—a critical detail. Because rainscreen systems are classified as a type of exterior wall covering, and wall coverings are integral components of exterior wall assemblies, rainscreens are now formally recognized as part of exterior wall assemblies under code.

This means that wherever the IBC outlines requirements for exterior wall assemblies, rainscreen systems are included by default. It’s important to distinguish between "exterior wall" and "exterior wall assembly," as the terms have different implications within the code.

While this update does not drastically change compliance requirements for rainscreens, it elevates their status as a mainstream and legitimate building practice. It also signals the industry's growing commitment to the careful and responsible design of rainscreen systems.

Reflecting on the past, it’s remarkable how perceptions have changed. Fifteen years ago, when the concept of open-joint panel systems and cavity drainage was introduced, many designers were shocked. Today, these ideas are widely accepted and are shaping how we design for durability and energy efficiency.

The Importance of Diligent Design

In rainscreen system design, several critical factors must be prioritized: drainage and ventilation, penetrations through control layers, and thermal performance. However, two issues stand above the rest: structural integrity and combustibility/flame propagation.

The 2024 IBC reinforces the need for rainscreen systems to meet structural load requirements as defined in Chapter 16 (Structural Design). While these requirements aren’t new, the explicit mention of rainscreens brings new visibility to their importance.

Design considerations must encompass both the cladding and the supporting framing systems, which must resist wind loads, dead loads, and other localized forces. This work often involves engineering analysis, testing, or a combination of both, and is frequently delegated to contractors or manufacturers. Regardless of who performs the design, thorough and diligent practices are essential for the safety and longevity of rainscreen assemblies.

As rainscreens evolve, challenges and learning opportunities arise. Success will depend on embracing continuous improvement, maintaining vigilance in design and construction, and collaborating closely with manufacturers and installers. Their deep understanding of system capabilities and practical constraints will be crucial as we push the envelope of building design in the years ahead.
